Heavy Duty Industrial Ventilation Fan Max Airflow 55000m³/h Greenhouse Circulation Fans
Basic Properties
Place of Origin:
China
Brand Name:
Terrui
Certification:
CE
Model Number:
YDA048DECKA0
Trading Properties
Minimum Order Quantity:
20
Price:
discuss
Payment Terms:
L/C,T/T
Product Summary
Energy-Saving Ventilation Fan featuring Advanced Rare Earth EC Motor Technology Slash your operational costs without sacrificing performance with our ultra-efficient exhaust fan. This unit is powered by advanced Rare Earth EC motor technology, which consumes up to 70% less energy than conventional ...
Product Details
Highlight:
45000m³/h Industrial Ventilation Fan
,Greenhouse Circulation Fans
,Heavy Duty Industrial Ventilation Fan
Product Name:
48''Exhaust Fan
Size:
1460*1460*580mm
Blade Diameter:
48''/1.22m
Installation:
Screw To The Frame On The Wall
Air Volume/W:
52.9m³/h
Current:
2.7A
Rotation Speed:
505r/min(20%-100% Speed Control)
Power:
3Φ/380V/50Hz
Protection Level:
IP55
Frame Material:
High-strength Fiberglass
Max Airflow:
55000m³/h
Motor:
Outer Rotor Permanent Magnet Brushless DC Motor
Type:
Industrial Exhaust Fan
Product Description
Energy-Saving Ventilation Fan featuring Advanced Rare Earth EC Motor Technology
Slash your operational costs without sacrificing performance with our ultra-efficient exhaust fan. This unit is powered by advanced Rare Earth EC motor technology, which consumes up to 70% less energy than conventional induction motors. The brushless design eliminates friction losses, ensuring that more power is converted directly into airflow. This translates to significant savings on your electricity bills over the fan's extended lifespan. Smart APP control further enhances efficiency, allowing you to run the fan at optimal speeds and only when necessary, maximizing your return on investment.
Technical Parameters:
Noise |
≤70dB |
Type |
Industrial exhaust fan |
Frame Material |
High-strength fiberglass |
Installation |
Screw to the frame on the Wall |
Product Model |
YDA048DECKA0 |
Motor |
Outer rotor permanent magnet brushless DC motor |
Power |
3Φ/380V/50Hz |
Input power |
1150w |
Max Airflow |
55000m³/h |
Air Volume/W |
52.9m³/h |
Rotation Speed |
505r/min(20%-100% Speed Control) |
Fan Blade Diameter |
48''/1.22m |
Product Name |
48’’/1.2M REFINE Exhaust fan |
Protection Level |
IP55 |
Current |
2.7A |
Frame Size |
1460*1460*580mm |
This fan is an ideal investment for any facility focused on reducing long-term energy consumption and operating costs. It is perfect for large commercial buildings, data centers, indoor farms, and public institutions where ventilation systems run for extended periods. By upgrading to this energy-saving technology, businesses can not only lower their utility expenses but also contribute to sustainability goals and reduce their carbon footprint, making it a smart choice for both your budget and the environment.
