Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor

Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor
Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor
Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor

Large Image :  Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor

Product Details:
Place of Origin: China
Brand Name: Terrui
Certification: CE
Model Number: DC 750
Payment & Shipping Terms:
Minimum Order Quantity: 10
Packaging Details: Carton
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 500pcs per month

Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor

Description
Keywords: PMSM Motor Mounting: Free Standing
Electric Current Type: DC Application: Industrial Ceiling Fan
Driving Type: Permanent Magnet Synchronization Rated Efficiency: ≥ 82%
Rated Speed: 60rpm Max Torque: 150Nm
High Light:

Brushless dc EC Motor

,

PMSM Synchronous EC Motor

,

Industrial Ceiling high power bldc motor

                             Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor 0



Technical Data:
Model: TSL05A3
Driving type: Permanent magnet synchronization
Rated Voltage: 220V/380V
Rated Power: 750W
Rated Torque :110Nm
Max Torque :150Nm
Rated Current :1.5A
Rated efficiency : ≥ 82%
Rated speed:60rpm
Working Temp:-20℃~40℃
Weight:38Kg

Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor 1



Voltage Motor Model Motor Power(W) RPM Current G.W(KG)
220v/380v M300 1500 0-100 14.2 35
220v/380v M300 1100 0-100 10.4 35
220v/380v M300 1100 0-80 10.4 35
220v/380v M198 550 0-80 5.2 30
220v/380v M198 550 0-80 5.2 30
220v/380v M198 350 0-75 3.3 30
220v/380v M198 350 0-75 3.3 30
220v/380v M147 200 0-75 1.9 26
220v/380v M147 180 0-100 1.7 26
220v/380v M147 100 0-110 0.9 26



EC motors are smaller than other ones and offer the same level of performance. This is because they don’t rely on carbon brushes and are controlled by external electronic circuit boards. As a result, they offer greater controllability and higher efficiency. So unlike DC or AC motors, EC motors only run as much as it’s needed with no excess use of energy.





Brushless Dc EC Motor PMSM Synchronous Industrial Ceiling High Power Bldc Motor 2
